型 号
|
|
CDD15P-LI
|
CDD16P-LI
|
CDD20P-LI
|
|
驱动方式
|
|
站驾
|
站驾
|
站驾
|
|
额定载荷
|
kg
|
1500
|
1600
|
2000
|
|
载荷中心距
|
mm
|
500
|
600
|
600
|
|
起升高度
|
mm
|
1600/2500/3000/3500/4000
|
2500/3000/3500/4000/5000/6000
|
2500/3000/3500/4000/5000/6000
|
|
门驾降低时高度
|
mm
|
2030/1780/2030/2280/2530
|
1760/2010/2260/1840/2180/2520
|
1760/2010/2260/1840/2180/2520
|
|
手配离地高度
|
mm
|
1450
|
1450
|
1450
|
|
作业时整车高大高度
|
mm
|
2030/2960/3460/3960/4460
|
2980/3480/3980/4480/5480/6480
|
2980/3480/3980/4480/5480/6480
|
|
货叉降低时高度
|
mm
|
90
|
90
|
90
|
|
整车长*宽
|
mm
|
2030*820
|
2080*820
|
2080*820
|
|
货叉尺寸
|
mm
|
55/160/1150
|
60/160/1150
|
60/160/1150
|
|
货叉外宽
|
mm
|
560/680
|
570/685
|
570/685
|
|
行走速度
|
km/h
|
4/4.5
|
5.5/5.8
|
5.5/5.8
|
|
转弯半径
|
mm
|
1560
|
1560
|
1560
|
|
驱动电机功率
|
KW
|
0.75
|
1.5
|
2.0(AC)
|
|
提升电机功率
|
KW
|
2.2
|
2.2
|
3
|
|
电池电压/容量
|
V/Ah
|
24/50(80/100/200)
|
24/50(80/100/200)
|
24/150(175/200/300)
|
